Specification
| Basic Information | ||
| Supported CPU | – Support for an Intel Core 2 Extreme processor/ Intel Core 2 Quad processor/Intel Core 2 Duo processor/ Intel Pentium processor/Intel Celeron processor in the LGA775 package (Go to GIGABYTE’s website for the latest CPU support list.) – L2 cache varies with CPU |
|
| Chipset | North Bridge: Intel G41 Chipset | |
| BIOS | – Use of licensed AWARD BIOS – Support for DualBIOS – PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b – Support for BIOS – Support for Xpress BIOS Rescue |
|
| Form Factor | Micro ATX Form Factor; 24.4cm x 21.0cm | |
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16 1 x PCI Express x1 slot 2 x PCI slots |
|
| Memory | ||
| Type | DDR3, DDR2: | |
| Graphics | ||
| Max Shared Memory | DDR3: 2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory (Note 1) Dual channel memory architecture Support for DDR3 1333(O.C.)/1066/800 MHz memory modules DDR2: 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory (Note 1) Dual channel memory architecture Support for DDR2 1066(O.C.)/800/667 MHz memory modules (Note: Mixed mode, populating DDR2 and DDR3 memory modules simulta- neously is not supported. Go to GIGABYTE’s website for the latest supported memory speeds and memory modules.) |
|
| Connector & Ports | ||
| D-Sub (s) | 1 x D-Sub port | |
| USB (s) | USB 2.0 Ports 4 Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers) 2 x USB 2.0/1.1 headers 4 x USB 2.0/1.1 ports |
|
| LAN Port (s) | 1 x Atheros AR8151 chip (10/100/1000 Mbit) | |
| Supported Storage | 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices iTE IT8718F chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive |
|
| Audio | High Definition Audio 1 x front panel audio header 3 x audio jacks (Line In/Line Out/Microphone) |
|
| Internal I/O Ports | I/O Controller : iTE IT8718F 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 4 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x clearing CMOS jumper |
|
| Warranty Information | ||
| Manufacturing Warranty | 1 Year | |
